WHEELBASE: 236”

TRAVEL HEIGHT: 11’ – 6”

TRAVEL LENGTH: 46’ – 7”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Domex Frame Rails (110K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 52,000 lbs
  • Engine: Cummins X 12, 500 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS 4000

PUMP:                 Hale

  • QMAX-2000 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right
  • Crosslays: (2) 2” w/ 1 ½” Swivel, (1) 2 ½” 2/ 2 ½” Swivel
  • 300-Gallon Water Tank

BODY:                  Sutphen

  • 3/16” Aluminum Mounting Plate
  • ROM Roll-Up Compartment Doors
  • 49 cu. ft. Total Compartment Space
  • Alco-Lite (24’ 2-Section & 35’ 2-Section & 14’ Combo & (2) 16’ Roof)

ADDITIONAL EQUIPMENT:

  • 12” Polished Stainless Steel Bumper Extension
  • Brigade, Backeye 360, Camera System
  • Federal Q2B Siren, Grille Mount
  • Air Bottle Compartments: 7
  • Smart Power 10KW Generator
  • Firetech 3-piece 72” LED Brow Light
  • Whelen Freedom IV LED Lightbar
  • FR Spectra 240V Scene Lights
  • FRC 950 LED Scene Lights
  • FRC Spectra 12V LED Scene Lights
  • FRC Spectra 240V LED Telelights
