Sutphen SP 70, Demo 472, HS #6605

WHEEL BASE: 221”

TRAVEL HEIGHT: 10 – 9 ¼”

TRAVEL LENGTH: 43’ – 5 ¾”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Upper Left Side, (1) 1 ½” Front Bumper,
  • Monitor: (2) Elkhart #293-6A W/CSW Nozzle
  • Crosslays: (2) Crosslays 2” Valve-Piping 1 ½” Swivel
  • 500-Gallon Water Tank
  • 30-Gallon Foam Tank

BODY:                  Sutphen

  • Huck Bolted #304 Stainless Steel
  • ROM Roll-Up Compartment Doors
  • Over 192 cu. ft. Total Compartment Space
  • Alco-Light Quint Ladder Compliment (85’: 16’ Roof, 24’ 2-Section, 35’ 3-Section & 10’ Folding)
  • SAA-4: Left High / Right Intermed / Transverse

ADDITIONAL EQUIPMENT:

  • 24” Polished Stainless Steel Bumper Extension
  • FRC, Inview Trueview Camera System
  • 8KW Smart Power Generator
  • Federal Q2B Grille Mount
  • LED Marker Lights
  • Hi-Viz 3-Piece 12V LED Brow Light
  • Whelen Freedom 4 Lightbar
  • Firetech LED Boom Spotlight
  • Firetech LED Aerial Illumination Lights
  • Firetech LED Platform Spotlight
  • FRC Spectra 240V LED Telescoping Scene Lights
