Demo 470 – SLR 108

WHEELBASE: 236”

TRAVEL HEIGHT: 12’

TRAVEL LENGTH: 41’ – 7 ¼”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab

• Four-Door, Six-Person Cab
• 10” Double Strenx Frame Rails (110K PSI)
• Front Axle and Suspension, STEERTEK 24,000 lbs
• Rear Axle and Suspension, Raydan 48,000 lbs
• Engine: Cummins X 12, 500 HP
• Alternator: Leece Neville, 320 AMP
• Transmission: Allison Gen 5, EVS4000

PUMP:                 Hale

• QMAX-1500 GPM, Single Stage Pump
• Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 1 ½” Front Bumper
• Crosslays: (2) 2” Valve-Piping 1 ½” Swivel
• Monitor: Akron 3480 Stream Madter Elec RF w/ 5178 Nozzle
• 400-Gallon Water Tank

BODY:                  Sutphen

• Huck Bolted #304 Stainless Steel
• ROM Roll-Up Compartment Doors
• Up to 240 cu. ft. Total Compartment Space
• Alco-Lite (PEL-24 24’ 2-Section & 35’ 2-Section & PRL-14 14’ Roof & (2) 16’ Roof & 10’ Folding)
• Body: TAA RM1, SLR 108

ADDITIONAL EQUIPMENT:

• 24” Polished Stainless Steel Bumper Extension
• Hannay Electric Cord Reel, 150’ (1)
• FRC Inview 360, Camera System
• Federal Q2B Siren, Grille Mount
• 10KW Smart Power Generator
• Pike Pole Storage Tubes (4)
• FRC ACT 2-Station Intercom System
• HIVIZ 3-piece 12V LED Brow Light
• Whelen FNMINI Lightbar
• Whelen M9V2R LED Scene Lights
• Firetech FT-WL-2000-S-B, LED Ladder Lighting System
