WHEEL BASE: 185”

TRAVEL HEIGHT: 9’ – 8”

TRAVEL LENGTH: 31’ – 8”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with a 10” Raised Roof

  • Four-Door, Five-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS 3000

PUMP:                 Hale

  • QMAX-1500 GPM, Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Right Rear, (1) 1 ½” Front Bumper Discharge, (1) 3” Deck Gun
  • Crosslays: (2) 2” w/ 1 ½” Swivel
  • 1,000-Gallon Water Tank
  • 30-Gallon Foam Tank

BODY:                  Sutphen

  • Amdor Roll-Up Compartment Doors
  • 3 cu. ft. Total Compartment Space
  • Duo-Safety 900A (24’ 2-Section & 14’ Roof & 10’ Folding)
  • Body: S2-Alum 43/53 Ladder Chute

ADDITIONAL EQUIPMENT:

  • 18” Polished Stainless Steel Bumper Extension
  • Brigade camera system
  • Federal Q2B Siren, Grille Mount
  • Air Bottle Compartments: 4
  • FRC Spectra 12V LED Brow Light
  • FRC Spectra Tele Lights
  • Whelen Freedom IV 72” LED Lightbar
  • FRC Spectra 900 12V LED Scene Lights
