Sutphen SP 70, Demo 464, HS #6523

WHEEL BASE: 221”

TRAVEL HEIGHT: 10’ – 9 ¼”

TRAVEL LENGTH: 43’ – 5 ¾”

CHASSIS:             Sutphen Monarch Heavy-Duty Custom Chassis, 62” Extended Cab with 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 23,000 lbs
  • Rear Axle and Suspension 31,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5, EVS 4000

PUMP                   Hale

  • QMAX-1500 GPM 6” Suction Single Stage
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Upper Left Side, (1) 1 ½” Front Bumper
  • Monitors: (2) Elkhart #293-6A w/ CSW Nozzle
  • Crosslays: (2) 2” Valve-Piping 1 ½” Swivel
  • 30-Gallon Foam Tank
  • 500-Gallon Water Tank

BODY:                  Sutphen

  • HuckBolted #304 Stainless Steel
  • ROM Roll-Up Compartment Doors
  • Over 192 cu. ft. Total Compartment Space
  • Alco-Lite Quint Ladder Compliment (85’: 16’R, 24’ 2-Section, 35’ 3-Section & 10’F)
  • Body SAA-4 Left High / Right Intermed / Trans

ADDITIONAL EQUIPMENT

  • 24” Polished Stainless Steel Bumper
  • FRC, Inview Trueview Camera System
  • Federal Q2B Siren, Grille Mount
  • 8KW Smart Power Generator
  • Hannay Electric Cord Reel, 150’ (1)
  • Pike Pole Storage Tubes (3)
  • Whelen Freedom 4 Lightbar
  • FRC Spectra 12V LED Brow Light
  • FRC Spectra 240V LED Fixed Scene Light
  • Firetech LED Rear Work Lights
  • Firetech LED Platform Spotlight
  • Firetech LED Aerial Illumination Lights
