THIS UNIT HAS BEEN SOLD – Please call the sales office for possible new units

Sutphen Custom Pumper, Demo 457, HS #6349

WHEEL BASE: 185”

TRAVEL HEIGHT: 9’ – 8”

TRAVEL LENGTH: 32’ – 1”

CHASSIS:             Sutphen Monarch Heavy Duty-Custom Chassis, 62” Extended Cab with a 10” Flat Roof

  • Four-Door, Six-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 24,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • QMAX-1500 GPM Single Stage Pump
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Crosslays: (1) 2 ½” Crosslay & (2) 2” Speedlays w/ 1 ½” Swivel and Poly Lift-Out Tray
  • 750-Gallon Water Tank
  • 30-Gallon Foam Tank

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • Amdor Roll-Up Compartment Doors
  • Over 222” cu. ft. Total Compartment Space
  • Alco-Lite (PEL-24 24’’ 2-Section & PRL-14 14’ Roof & 10’ Folding)
  • Ladder Chute with Backboard Storage

ADDITIONAL EQUIPMENT:

  • Safety Vision SV-CLCD0-70, Camera System
  • Federal Q2B Siren, Grille Mount
  • 24” Polished Stainless Steel Bumper Extension
  • Whelen Freedom IV LED Lightbar
  • FRC Spectra 12V LED Brow
  • FRC Spectra 12V LED Scene
  • Rigid LED Work Lights
