Sutphen Custom Pumper, Demo 449, HS #6285

WHEEL BASE: 196”

TRAVEL HEIGHT: 9’ – 8”

TRAVEL LENGTH: 32’ – 11”

CHASSIS:             Sutphen Monarch Heavy Duty-Custom Chassis, 73” Extended Cab with a 10” Raised Roof

  • Four-Door, Six-Person Cab
  • 10” Double Frame Rails (50K PSI)
  • Front Axle and Suspension 20,000 lbs
  • Rear Axle and Suspension 27,000 lbs
  • Engine: Cummins L 9, 450 HP
  • Alternator: Leece Neville, 320 AMP
  • Transmission: Allison Gen 5, EVS3000

PUMP:                 Hale

  • XS QMAX-1500 GPM Single Stage
  • Discharges: (2) 2 ½” Left, (1) 3” Right, (1) 2 ½” Right, (1) 2 ½” Left Rear, (1) 2 ½” Right Rear, (1) 1 ½” Front Bumper, (1) 3” Deck Gun
  • Crosslays: (1) 2 ½” Crosslay & ( 2) 2” Speedlays w/ 1 ½” Swivel and Poly Lift-Out Tray
  • Monitor: Akron 3423 Apollo
  • 30-Gallon Foam Tank
  • 1,000-Gallon Water Tank

BODY:                  Sutphen

  • 3/16” Extruded Aluminum
  • ROM Roll-Up Compartment Doors
  • Over 233” cu. ft. Total Compartment Space
  • Alco-Lite (PEL-24 24’’ 2-Section & PRL-14 14’ Roof & 10’ Folding)
  • Ladder Chute w/ Backboard Storage

ADDITIONAL EQUIPMENT:

  • Federal Q2B Siren, Flush Grille Mount
  • 24” Polished Stainless Steel Bumper Extension
  • Camera System for Eskey, Rear
  • Whelen Freedom IV (12) LED Lightbar
  • FRC Spectra Max 12V LED Brow
  • FRC Spectra 12V LED Tele
  • FRC Spectra 900 12V LED Scene
