WHEEL BASE: 173”

TRAVEL HEIGHT: 9’-8”

TRAVEL LENGTH: 29′-7″

CHASSIS:              Sutphen 62”cab with 10” half raised roof

  • Four-Door, Six-Person Cab
  • Front Axle and Suspension: 20,000 lbs.
  • Rear Axle and Suspension: 27,000 lbs.
  • Engine: Cummins ISL 9 450HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen IV

PUMP:                  Hale

  • QMAX-XS-1500 GPM 6” Suction Single Stage
  • Discharge: 2.5” Left, 2.5” Right, 3” Right, 3” Valve, 3” Pipe to Left Rear, 5” Rear, 2” Rear, 3” Deluge Riser, 3” Front Bumper, 1.5” Front Bumper, 2” Plumbing,
  • 1000-Gallon Water Tank
  • 20-Gallon Foam Tank
  • Hale Foamlogix 5.0

BODY:                   Sutphen

  • 3/16″ Extruded Aluminum
  • Hinged Compartment Doors
  • Alco-Lite (PEL-24 24′ 2-Section & PRL-14 14’Roof & 10′ Folding)

OPTIONAL EQUIPMENT:

  • 6KW HYD Harrison Generator
  • Ziamatic Hydraulic Ladder Rack
  • Ziamatic SAC-44 Folding Wheel Chock Mounted
  • Alco-Lite Pel-24 24’2 Sec & PRL-14 14′ Roof
  • Federal Signal 72″ Lightbar
