WHEEL BASE:  236″

TRAVLE HEIGHT: 11′-6″ ±2″

TRAVEL LENGTH: 46′-7″

CHASSIS:              Sutphen 62” Cab with 10” half raised roof

  • Four-Door, Six-Person Cab
  • Front Axle and Suspension: 23,000 Lbs.
  • Rear Axle and Suspension: 52,000 Lbs.
  • Engine: Cummins X12 500HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5

Pump

  • QMAX-2000 GPM Single Stage Pump
  • Discharge: (2) 2.5” Left, 3” Right, 2.5” Right,
  • 300 Gallon Water Tank

BODY:                   Sutphen

  • Aluminum
  • 293 cu. ft. Total Compartment Space

OPTIONAL EQUIPMENT:

  • Harrison 10 KW HYD Generator
  • Ziamatic SAC-44 Folding Wheel Chocks
  • 120V Shoreline Inlet, Kussmaul Super 20 Auto Eject Deluxe Cover with Display
  • Haas Alert R2V System
  • Additional Brigade Camera System Monitor, Waterproof
  • Hanger Bar for Safety Belts
  • Scene light, LED, Brow, Whelen Pioneer PFH2, 12V
