WHEEL BASE:  196″

TRAVEL HEIGHT: 9′-10″

TRAVEL LENGTH: 32′-9″

CHASSIS:              Sutphen 73” Cab with 10” half raised roof

  • Four-Door, Six-Person Cab
  • Front Axle and Suspension: 20,000 Lbs.
  • Rear Axle and Suspension: 27,000 Lbs.
  • Engine: Cummins L 9 450HP
  • Alternator: Leece Neville 320 AMP
  • Transmission: Allison Gen 5

BODY:                   Sutphen

  • Aluminum
  • 246 cu. ft. Total Compartment Space

PUMP:                  Hale

  • QMAX 1500 GPM Single Stage
  • Discharge: (2) 2.5” Left, 3” Right, 2.5” Right, 2.5” Right Rear, 1.5” Front Bumper, 2” Plumbing, 3” Deck Gun,
  • 1000 Gallon Water Tank

OPTIONAL EQUIPMENT:

  • Amdor Strip Lighting in Compartment
  • Triple Bottle Wheel well Storage
  • Oil Dry Hopper Wheel well Storage
  • Lightbar and Rear Beacons to have “cruise light” wired to switch in overhead console panel 1.
